Using Tor for Onion Encryption / Authentication and NAT Traversal Only - Without Anonymity!

Not anonymous!

Documentation for this is incomplete. Contributions are happily considered! See this for potential alternatives.


It is possible to make Tor on a server using a single Tor hop (only one Tor relay instead of three) by using Tor configuration options HiddenServiceNonAnonymousMode 1, HiddenServiceSingleHopMode 1. This is non-anonymous but faster. Server should use Onions Services Authentication. The advantage of this is to have a server which is:

  • reachable (for users having access to Tor) for NAT traversal, i.e. it works behind common NAT routers.
  • capable to secure inherently insecure protocols (such as VNC) by using the encryption / authentication provided by Tor Onion Services

Independently, if clients prefer speed over anonymity, they can configure Tor in Tor2Web mode, which means outgoing Tor circuits will have a length of one rather than three.

These two options combined reduce a 6 hop Tor connection to a 2 hop Tor connection. It's not anonymous, but providing NAT traversal as well as onion encryption / authentication.

Server Side[edit]

Open /usr/local/etc/torrc.d/50_user.conf.

If you are using Kicksecure inside Qubes, complete the following steps.

Qubes App Launcher (blue/grey "Q")Kicksecure ProxyVM (commonly named kicksecure)Tor User Config (Torrc)

If you are using a graphical Kicksecure, complete the following steps.

Start MenuApplicationsSettings/usr/local/etc/torrc.d/50_user.conf

If you are using a terminal-only Kicksecure, complete the following steps. sudo nano /usr/local/etc/torrc.d/50_user.conf


HiddenServiceNonAnonymousMode 1 HiddenServiceSingleHopMode 1 SocksPort 0 HiddenServiceDir /var/lib/tor/hidden_service/ HiddenServicePort 22 HiddenServicePort 5900 HiddenServiceVersion 3 ## syntax: ## HiddenServiceAuthorizeClient auth-type client-name,client-name,… ## The auth-type can either be 'basic' for a general-purpose authorization protocol or 'stealth' for a less scalable protocol that also hides service activity from unauthorized clients. ## Valid client names are 1 to 16 characters long and only use characters in A-Za-z0-9+-_ (no spaces). HiddenServiceAuthorizeClient stealth 1234567890123456

Save and exit.

Client Side[edit]

Update the package lists.

sudo apt update

Install Tor's build dependencies.

sudo apt build-dep tor


Create directory ~/tor-src.

mkdir ~/tor-src

Change directory to ~/tor-src.

cd tor-src

Download the Tor source package.

apt source tor

Change directory to Tor source directory.

cd tor-*/

Open file debian/rules in a text editor of your choice as a regular, non-root user.

If you are using a graphical environment, run. mousepad debian/rules

If you are using a terminal, run. nano debian/rules


dh_auto_configure \ $(confflags) \ --prefix=/usr \ --mandir=\$${prefix}/share/man \ --infodir=\$${prefix}/share/info \ --localstatedir=/var \ --sysconfdir=/etc \ --disable-silent-rules \ --enable-gcc-warnings-advisory


dh_auto_configure \ $(confflags) \ --prefix=/usr \ --mandir=\$${prefix}/share/man \ --infodir=\$${prefix}/share/info \ --localstatedir=/var \ --sysconfdir=/etc \ --disable-silent-rules \ --enable-gcc-warnings-advisory \ --enable-tor2web-mode

Open file src/or/config.c in a text editor of your choice as a regular, non-root user.

If you are using a graphical environment, run. mousepad src/or/config.c

If you are using a terminal, run. nano src/or/config.c


V(Tor2webMode, BOOL, "0"),


V(Tor2webMode, BOOL, "1"),

Build the Tor package.




Unfinished: This wiki is a work in progress. Please do not report broken links until this notice is removed, use Search Engines First and contribute improving this wiki.
