Design Previous page: Dev/Derivative-Maker Index page: Design Next page: Dev/Expected Build Warnings Build Configuration

Kicksecure Build Configuration. APT Repository, Onion Sources, APT Cache, VM Settings, Skip Steps, Source Code Changes

Note: All of the following build configuration steps are optional.

Introduction[edit]

Usually the build configuration does not need to be changed. Kicksecure built from source code comes with safe defaults. The derivative APT Repository will not be used.

The most interesting build configurations (Terminal-Only, NoDefaultApps etc.) are documented in the following chapters.

If you are interested, click on Expand on the right.

If build configurations were used earlier, it might be better to delete the build configuration folder. A few example filenames may have changed since the last build.

sudo rm -r /etc/buildconfig-dist.d

Alternatively, experts can manually examine the /etc/buildconfig-dist.d folder and change its contents to suit their preferences.

/etc/buildconfig-dist.d is a modular flexible .d style configuration folder.

Less popular build configurations are documented in the buildconfig.d folder and on the Dev/Source_Code_Intro#Build_Configuration page, but it is less user-friendly.

To avoid typos, it is best to copy and paste text when creating build configuration files. Take care that editors do not capitalize variable names which are supposed to be lower case during copy and paste procedures.

Platforms Choice[edit]

Advanced users can create 32-bit instead of 64-bit builds.

If you are interested, click on Expand on the right.

  • Kicksecure 14 and above is 64-bit by default. [1] [2]

To build Kicksecure 14 32-bit, add the following build parameter.

--arch i386
  • kFreeBSD is entirely untested and most likely needs additional work (see footnotes). [3]

Kicksecure APT Repository[edit]

Kicksecure:
Kicksecure APT Repository is disabled by default [6] for builds from source code for reasons of Trust. Users can decide to update Kicksecure Debian packages by building them from source code (greater security). Alternatively, Kicksecure APT repository can be enabled right after building or after booting the build for the first time (greater convenience) using Kicksecure repository tool. To use the latter method which sacrifices security for convenience, click on Expand on the right side.

Do you want to opt-in Kicksecure APT Repository?

The easy way to add Kicksecure stable repository the following command line option can be used.

--repo true

Other settings can be set using an environment variable or build configuration. Below are examples using an environment variable.

DERIVATIVE_APT_REPOSITORY_OPTS='--enable --repository stable' DERIVATIVE_APT_REPOSITORY_OPTS='--enable --repository testers' DERIVATIVE_APT_REPOSITORY_OPTS='--enable --repository developers' DERIVATIVE_APT_REPOSITORY_OPTS='--enable --codename bookworm'

Add an environment variable as one normally does on that specific Linux platform. For example, to enable the Kicksecure stable repository during build, you could set DERIVATIVE_APT_REPOSITORY_OPTS by interjecting it between sudo and the ./derivative-maker command. Below is an example. Do not use [...]. Replace it with other chosen build parameters (such as --build, --target etc.) after ./derivative-maker.

sudo DERIVATIVE_APT_REPOSITORY_OPTS='--enable --repository stable' ./derivative-maker [...]

APT Onion Build Sources[edit]

For better build security, you can also use onions apt sources for building Kicksecure.

If you are interested, click on Expand on the right.

This does not ensure all build process networking will be torified!

Kicksecure 14 and above only:

--connection onion

1) Also chapter below has to be considered.

2) See also: https://forums.whonix.org/t/derivative-maker-fails-with-onion-sources/20200archive.org iconarchive.today icon

Torified or Host APT Cache[edit]

Using an apt cache will greatly improve build speed when building several times in a row (e.g. when debugging, during development). Kicksecure build script sets up an apt cache by default.

If you are interested in a torified apt-cacher-ng or host apt-cacher-ng, click on Expand on the right.

torified apt-cacher-ng

Notes:

  • The following torified apt-cacher-ng setup only has to be applied, if you are building using onion apt sources using --connection onion.
  • When building inside Whonix, this is not required.

Note, this neither torifies all of the build script's connections nor hides Tor from your ISP! See Build AnonymityOnion network Logo.

The goal of this is to torify apt-cacher-ng using torsocks so it will be able to connect to onions.

Note: This is currently broken. No fix available. Undocumented.

1. Install apt-cacher-ng, torsocks and tor.

sudo apt install apt-cacher-ng torsocks tor

2. Create folder apt-cacher-ng systemd drop-in folder /lib/systemd/system/apt-cacher-ng.service.d.

sudo mkdir -p /lib/systemd/system/apt-cacher-ng.service.d

3. Open file /lib/systemd/system/apt-cacher-ng.service.d/50_user.conf in an editor with root rights.

Select your platform.

Kicksecure

See Open File with Root Rights for detailed instructions on why to use sudoedit for better security and how to use it.

Note: Mousepad (or the chosen text editor) must be closed before running the sudoedit command.

sudoedit /lib/systemd/system/apt-cacher-ng.service.d/50_user.conf

Kicksecure for Qubes

NOTES:

sudoedit /lib/systemd/system/apt-cacher-ng.service.d/50_user.conf

  • After applying this change, shutdown the Template.
  • All App Qubes based on the Template need to be restarted if they were already running.
  • This is a general procedure required for Qubes and unspecific to Kicksecure for Qubes.

Others and Alternatives

  • This is just an example. Other tools could achieve the same goal.
  • If this example does not work for you or if you are not using Kicksecure, please refer to this link.

sudoedit /lib/systemd/system/apt-cacher-ng.service.d/50_user.conf

4. Add. [7]

[Service] ExecStart= ExecStart=torsocks /usr/sbin/apt-cacher-ng SocketPath=/run/apt-cacher-ng/socket -c /etc/apt-cacher-ng ForeGround=1

5. Save.

6. Reload systemd.

sudo systemctl daemon-reload

7. Restart apt-cacher-ng.

sudo systemctl restart apt-cacher-ng

8. Done.

The process of torification of apt-cacher-ng has been completed.

9. Broken!

/etc/tor/torsocks.conf add:

AllowInbound 1 AllowOutboundLocalhost 1

But this is also insufficient.

sudo journalctl -f -u apt-cacher-ng

shows errors:

WARNING torsocks[17645]: Config file not found: /etc/tor/torsocks.conf. Using default for Tor (in config_file_read() at config-file.c:583)
Couldn't listen on socket: Operation not permitted
Error creating socket: Function not implemented

No fix available. Help welcome.

host apt-cacher-ng

This is probably only useful for developers. Most users will not need the complexity of an apt-cacher-ng running outside of the VM which runs derivative-maker or on another computer.

Be sure to have a firewall, so the whole internet cannot use the apt-cacher-ng service.

When building inside a non-Whonix VM, an apt cache can be used on the host. In that case, adjust the IP accordingly and manually test that it is reachable. When building inside a (Kicksecure) VM, just install the apt cache inside the VM and point to a localhost apt cache.

Prepend REPO_PROXY=http://127.0.0.1:3142archive.org iconarchive.today icon before the build command.

Replace the IP 127.0.0.1 with the IP address of your host. For security reasons, this should only be done over LAN and not over the internet.

sudo REPO_PROXY=http://127.0.0.1:3142 ./derivative-maker ...

VM Settings[edit]

If building VMs, settings such as image size, RAM, filesystem, hostname and password can be customized.

If you are interested, press on expand on the right side.

This is only relevant for VM builds.

Several examples are below. Values can be changed to suit user preferences.

VirtualBox's --vmsize option (virtual RAM).

--vmram 128

VirtualBox's --vram option (virtual video RAM).

--vram 12

grml-debootstrap's --vmsize option.

--vmsize 200G

grml-debootstrap's --filesystem option.

--file-system ext4

grml-debootstrap's --hostname option. [8]

--hostname host

grml-debootstrap's --password option.

--os-password changeme

grml-debootstrap's --debopt option.

--debopt "--verbose"

Build Variables Changes[edit]

It is possible to add build configuration files snippets which can change build variables.

Build Configuration Folders:

You can drop configuration file either in:

  1. buildconfig.d or in
  2. /etc/buildconfig-dist.d
  3. ../buildconfig.d folder.

Files should have the file extension .conf.

Method 2. is recommended for users.

  1. Contains examples. It is more difficult to use. [9] Rather use the following.
  2. sudo mkdir --parents /etc/buildconfig-dist.d
  3. When /home/user/Kicksecure is your Kicksecure source folder, you could use /home/user/buildconfig.d as your Kicksecure build configuration folder. It is easier to use, since you don't have to git commit your build config files.

[10]

Below is an example how to use method 2.

sudo mkdir /etc/buildconfig-dist.d

Open file /etc/buildconfig-dist.d/50_user.conf in an editor with root rights.

Select your platform.

Kicksecure

See Open File with Root Rights for detailed instructions on why to use sudoedit for better security and how to use it.

Note: Mousepad (or the chosen text editor) must be closed before running the sudoedit command.

sudoedit /etc/buildconfig-dist.d/50_user.conf

Kicksecure for Qubes

NOTES:

sudoedit /etc/buildconfig-dist.d/50_user.conf

  • After applying this change, shutdown the Template.
  • All App Qubes based on the Template need to be restarted if they were already running.
  • This is a general procedure required for Qubes and unspecific to Kicksecure for Qubes.

Others and Alternatives

  • This is just an example. Other tools could achieve the same goal.
  • If this example does not work for you or if you are not using Kicksecure, please refer to this link.

sudoedit /etc/buildconfig-dist.d/50_user.conf

Add. (Replace it with whatever build configuration variable you wish to set.)

Example 1.

export DERIVATIVE_APT_REPOSITORY_OPTS='--enable --repository stable'

Example 2.

export tbb_version=13.0.1

Save.

Done.

Skip Steps[edit]

Developers users can speed up the build and skip sanity tests.

If you are interested, click on Expand on the right.

--sanity-tests false

Source Code Changes[edit]

This is only required if changes were made to the derivative-maker source folder! In that case click on Expand on the right.

This is not required if only a customized build configuration was added to the /etc/buildconfig-dist.d.d folder.

If changes were made to the derivative-maker source code, it is the easiest to use the following build parameter.

--allow-uncommitted true

Or if not building from a git tag, it is the easiest to use the following build parameter.

--allow-untagged true

Otherwise, changes must be committed to git first, before creating a git tag.


Footnotes[edit]

  1. ↑ State of official 64-bit buildsarchive.org iconarchive.today icon.
  2. ↑ Don't get confused by the term amd64. It runs on both, Intel and AMD. amd64 is only how Debian names the kernel. It works equally well on Intel and AMD.
  3. ↑ kFreeBSD (32-bit).
    --arch kfreebsd-i386 --kernel kfreebsd-image --headers kfreebsd-headers

    kFreeBSD (64-bit).

    --arch kfreebsd-amd64 --kernel kfreebsd-image --headers kfreebsd-headers
  4. ↑ https://github.com/grml/grml-debootstrap/pull/13archive.org iconarchive.today icon
  5. ↑ In this case, try installing the packages linux-image-amd64 and linux-headers-amd64 on your host, then boot the amd64 kernel by choosing it in the boot menu. The whole system does not require re-installation; just be sure to boot with an amd64 kernel. Alternatively, consider to re-install your host using amd64.
  6. ↑ Since Kicksecure 7.3.3
  7. ↑
    • The first ExecStart= is to disable the default ExecStart in /lib/systemd/system/apt-cacher-ng.service.
    • This is based on /lib/systemd/system/apt-cacher-ng.service .
    • Only torsocks is prepended in front of /usr/sbin/apt-cacher-ng
    • No other changes.
  8. ↑ The dist-base-filesarchive.org iconarchive.today icon package will change this later on.
  9. ↑ Since you would have to either:
    • A) git commit your build config files, OR,
    • B) See chapter source code changes below.
  10. ↑ This is because .. means "one level below this folder".
